10.1.2 Altitude
Altitude range of the Commander S100 is 0 to 3,000 m (9,900 ft), subject to the following conditions:
• 0 m to 1000 m above sea level: no derate required.
• 1,000 m to 3,000 m (3,300 ft to 9,900 ft) above sea level: de-rate the maximum output current from the specified figure by 1 % per 100 m (330 ft)
above 1,000 m (3,300 ft). For example at 3,000 m (9,900 ft) the output current of the drive would have to be de-rated by 20 %.
200 V Drive (200 to 240 V ±10 %)
S100-01S13 0.18 0.25 1.4 1.2 1.2 1.2 1 1
S100-01213 0.18 0.25 1.4 1.2 1.2 1.2 1 1
S100-02S11 0.18 0.25 1.2 1 1 1 0.8 0.8
S100-01S23 0.25 0.33 1.6 1.4 1.4 1.4 1.2 1.2
S100-01223 0.25 0.33 1.6 1.4 1.4 1.4 1.2 1.2
S100-02S21 0.25 0.33 1.4 1.2 1.2 1.2 1 1
S100-01S33 0.37 0.5 2.4 1.6 1.6 1.6 1.4 1.4
S100-01233 0.37 0.5 2.4 1.6 1.6 1.6 1.4 1.4
S100-02S31 0.37 0.5 2.2 1.4 1.4 1.4 1.2 1.2
S100-01S43 0.55 0.75 3.5 2.4 2.4 2.4 1.6 1.6
S100-01243 0.55 0.75 3.5 2.4 2.4 2.4 1.6 1.6
S100-02S41 0.55 0.75 3.2 2.2 2.2 2.2 1.4 1.4
S100-01S53 0.75 1 4.6 3.5 3.5 3.5 2.4 2.4
S100-01253 0.75 1 4.6 3.5 3.5 3.5 2.4 2.4
S100-02S51 0.75 1 4.2 3.2 3.2 3.2 2.2 2.2
S100-01D63 1.1 1.5 6.6 4.6 4.6 4 3.5 3.5
S100-02S61 1.1 1.5 6 3.6 4.2 3.4 3.2 2.8
S100-01D73 1.5 2 7.5 6.6 6.6 5.5 4.6 4.6
S100-02S71 1.5 2 6.8 6 6 5.5 4.2 4.2
S100-03D13 2.2 3 10.6 6.8 7.5 6.6 6.6 5.5
400 V Drive (380 to 480 V ±10 %)
S100-02413 0.37 0.5 1.2
1 0.8
S100-02423 0.55 0.75 1.7 0.5 1.2 1
S100-02433 0.75 1 2.2 0.6 1.7 1.2
S100-02443 1.1 1.5 3.2 0.8 2.2 0.5 1.7
S100-02453 1.5 2 3.7 1 3.2 0.55 2.2
S100-02463 2.2 3 5.3 1.2 3.7 0.55 3.2
S100-03413 3 3 7.2 2.2 5.3 1.2 3.7 0.8
S100-03423 4 5 8.8 3.2 7.2 1.2 5.3 1
Drive Model Number
Nominal Power
Rating
Maximum continuous
output current @ 40
o
C
Maximum continuous
output current @ 50
o
C
Maximum continuous
output current @ 60 °C
kW hp
4 kHz 12 kHz 4 kHz 12 kHz 4 kHz 12 kHz
