7 Drive parameters
Parameters are variables within the drive that can be used to monitor output levels and drive statuses or to control the settings within the drive.
Parameters are divided into six menus based on their function, these menus are:
Menu 1 - Status & Monitoring (All read-only parameters)
Menu 2 - References and Ramps
Menu 3 - Motor Setup
Menu 4 - General
Menu 5 - PID Controller
Menu 6 - IO Configuration
There is also a FastStart menu (Menu 0) that contains shortcuts to ten parameters used for basic drive setup. Because parameters in Menu 0 are
shortcuts, changing the value of the parameter in menu 0 will also change the value in its original menu and vice versa.
7.1 Menu 0 - FastStart
For a description of a parameter in menu 0, refer to the alternative location of the parameter in section 7.3 Parameter descriptions.
Parameter
Range Default
Alternative
Location
P0.01 Minimum Frequency Limit 0.0 to 300.0 Hz 0 Hz P2.01
P0.02 Maximum Frequency Limit 0.0 to 300.0 Hz 50 Hz: 50.0 Hz, 60 Hz: 60.0 Hz P2.02
P0.03 Acceleration Rate 1 0.0 to 1999.9 s/Hz(max) 5.0 s/Hz (max) P2.07
P0.04 Deceleration Rate 1 0.0 to 1999.9 s/Hz(max) 10.0 s/Hz (max) P2.08
P0.05 Frequency Reference Configuration
Custom (0),
Local/Remote (1),
Voltage/Preset Input (2),
Current/Preset Input (3),
Presets (4),
Keypad (5),
Terminal Up/Down (6),
Frequency Input (7),
PID Voltage Ref. (8),
PID + Feed Forward (9)
Local / Remote (1) P2.03
P0.06 Motor Rated Current 0.00 to Drive Rated Current A Rating Dependent P3.01
P0.07 Motor Rated Speed 0 to 18000 rpm 50 Hz: 1500 rpm, 60 Hz: 1800 rpm P3.02
P0.08 Motor Rated Voltage 0 to Drive Rated Voltage V Rating Dependent P3.03
P0.09 Motor Rated Power Factor 0.00 to 1.00 0.80 P3.04
P0.10 Run/Stop Configuration
Custom (0),
Enable + Run Forward + Run Reverse (1),
Run Forward + Run Reverse (3 Wire) (2),
Enable + Run + Reverse (3),
Run + Reverse (3 Wire) (4),
Run + Jog (3 Wire) (5),
Run Forward + Run Reverse (2 Wire) (6),
Run + Reverse (2 Wire) (7),
Keypad (8),
Keypad With Enable (9),
Keypad Jog (10)
Enable + Run Forward + Run Reverse (1) P6.13
