Nidec Control Techniques M701 User Manual

Safety information Introduction Product information System configuration
Mechanical
Installation
Electrical Installation
Unidrive M Modular Installation Guide 17
Issue Number: 2
Figure 3-3 Typical Rectifier rating label
Refer to Figure 2-8 Rectifier model number on page 10 for further information relating to the labels.
Figure 3-4 Typical master pod rating labels
Approvals
Input voltage
Output
voltage
Customer and
date code
Serial
number
Input
frequency
No.of phases &
Typical input current for
Normal Duty rating
Output current
RECT-106 02480 A STDN39
I/P 500-690V 50-60Hz 3ph 202A
O/P 640-1067V 247A
Designed in UK
Made in U.K.
Serial No: 3000005001
Input current
Output current
Model
Input
frequency
Customer and
date code
Approvals
Serial
number
Output
voltage
Input
voltage
Refer to
User Guide
Model
Frame
size
Voltage
Current rating
Drive format
RECT-106 02480 A
Key to approvals
CE approval Europe
C Tick approval Australia
UL / cUL approval
USA &
Canada
RoHS compliant Europe
R
M700-MASTER
STDN39 Customer and date code
Approvals
Serial numbers
M700-MASTER
Model
Key to approvals
CE approval Europe
C Tick approval Australia
UL / cUL approval
USA &
Canada
RoHS compliant Europe
R
