18 Unidrive M Modular Installation Guide
Issue Number: 2
Figure 3-5 Typical follower pod rating label
Figure 3-6 Power options available for Unidrive M
* Limit drive output current to rating of dual output sharing choke.
Table 3-7 Through panel mounting kits
A separate input line reactor of at least the value shown in Table 6-2 to Table 6-3 on page 59 and must be used with the rectifiers. Failure
to provide sufficient reactance could damage or reduce the service life of the rectifier or inverter.
Model
Serial number
Customer and date code
M000-FOLLOWER
STDN39
Approvals
Key to approvals
CE approval Europe
C Tick approval Australia
UL / cUL approval
USA &
Canada
RoHS compliant Europe
Single input line reactor
(INLX0X)
Dual output sharing choke
(OTLX1X)
for parallel
module drives
*
Single output sharing choke
(OTLX0X) for parallel
module drives
EMC filter
Finger-guard
grommet double
entry 3470-0107
Lifting
bracket
6541-0073
Part number Description
3470-0108 Inverter high IP insert
3470-0106 Rectifier high IP kit
