Nidec Control Techniques M701 - Layout for two size 9 A modules operating on a 3-phase AC supply

Safety information Introduction Product information System configuration
Mechanical
Installation
Electrical Installation
Unidrive M Modular Installation Guide 21
Issue Number: 2
Figure 4-3 Layout for two size 9A modules operating on a 3-phase AC supply
L3
L2
L1
Fuses Fuses
Master Follower
OTLXXX
sharing
chokes
UVW UVW
Paralleling cable
OTLXXX
sharing
chokes
9A 9A
