Safety information Introduction Product information System configuration
Mechanical
Installation
Electrical Installation
22 Unidrive M Modular Installation Guide
Issue Number: 2
Figure 4-4 Layout for two size 9E or 10E modules operating on a 3-phase AC supply
L3
L2
L1
Fuses
Fuses
Master Follower
OTLXXX
sharing
chokes
UVW UVW
Paralleling cable
OTLXXX
sharing
chokes
9E 10E 9E 10E
INLXXX
Line reactor
INLXXX
Line reactor
