Safety information Introduction Product information System configuration
Mechanical
Installation
Electrical Installation
38 Unidrive M Modular Installation Guide
Issue Number: 2
Figure 5-18 Through-panel mounting the Unidrive M size 9D/10D
285 mm (11.22 in)
310 mm (12.21 in)
340 mm (13.39 in)
773 mm (30.43 in)
190 mm (7.48 in)
99 mm (3.90 in)
714 mm (28.11 in)
693.7
231 mm (9.09 in)
406 mm (15.98 in)
586 mm (23.07 in)
30 mm
(1.18 in)
211 mm (8.31 in)
386 mm (15.20 in)
566 mm (22.28 in)
755 mm (29.72 in)
Æ5.5 mm (0.22 in)
x 6 holes
Æ9 mm (0.22 in)
x 4 holes
259 mm (10.20 in)
290 mm (11.42 in)
327 mm (12.87 in)
