Nidec Control Techniques M701 User Manual

Safety information Introduction Product information System configuration
Mechanical
Installation
Electrical Installation
Unidrive M Modular Installation Guide 39
Issue Number: 2
Figure 5-19 Through-panel mounting the Unidrive M size 9A
Figure 5-20 Through-panel mounting the Unidrive M (Rectifier)
341 mm (13.42 in)
285 mm (11.22 in)
310 mm (12.20 in)
1108 mm (43.61 in)
190 mm (7.48 in)
100 mm
(3.94 in)
1049 mm (41.31 in)
259 mm (10.18 in)
288 mm (11.34 in)
328 mm (12.90 in)
Æ9.0 mm (0.35 in)
x 4 holes
942 mm (37.08 in)
734 mm (28.89 in)
491 mm (19.32 in)
231 mm (9.09 in)
Æ5.0 mm (0.21 in)
x 8 holes
32 mm
(1.24 in)
211 mm (8.30 in)
471 mm (18.54 in)
714 mm (28.10 in)
923 mm (36.33 in)
1058 mm (41.66 in)
275.6
259 mm (10.20 in)
290 mm (11.42 in)
327 mm (12.87 in)
∅
9.0 mm (0.35 in)
x 4 holes
1
6
8
m
m
(
6
.
6
1
i
n
)
30 mm
(1.18 in)
148 mm (5.83 in)
338 mm (13.31 in)
∅
5.5 mm (0.22 in)
x 2 holes
190 mm (7.48 in)
99 mm (3.90 in)
296 mm (11.65 in)
339 mm (13.35 in)
310 mm (12.21 in)
285 mm (11.22 in)
355 mm (13.98 in)
