Refer to section
on page 89
for further information.
7 Digital Input 4
8
Digital Input 5
Terminal 7 default function
RUN FORWARD input
Terminal 8 default function
RUN REVERSE input
Type Negative or positive logic digital inputs
Logic mode controlled by... Pr 08.029
Voltage range 0 V to +24 V
Absolute maximum applied
voltage range
-3 V to +30 V
Impedance
>2 mA @15 V from IEC 61131-2, type 1,
6.6 k Ω
Input thresholds 10 V ±0.8 V from IEC 61131-2, type 1
Sample / Update period
250 µs when configured as an input with
destinations Pr 06.035 or Pr 06.036. 600 µs
when configured as an input with destination
Pr 06.029. 2 ms in all other cases.
9 +24 V external input
Function
To supply the control circuit
without providing a supply to the
power stage
Programmability
Can be used as a digital input when using
an external 24 Vdc
Sample / Update period 2 ms
Nominal voltage +24.0 Vdc
Minimum continuous operating
voltage
+19.2 Vdc
Maximum continuous operating
voltage
+28.0 Vdc
Minimum start-up voltage 21.6 Vdc
Recommended power supply 40 W 24 Vdc nominal
Recommended fuse 3 A, 50 Vdc
10 0 V common
Function
Common connection for all
external devices
12 0 V common
Function
Common connection for all
external devices
11 SAFE TORQUE OFF function input 1 (drive enable)
13
SAFE TORQUE OFF function input 2 (drive enable)
Type Positive logic only digital input
Voltage range 0 V to +24 V
Absolute maximum applied
voltage
30 V
Logic Threshold 10 V ± 5 V
Low state maximum voltage for
disable to SIL3 and PL e
5 V
Impedance
>4 mA @15 V from IEC 61131-2, type 1,
3.3
k Ω
Low state maximum current for
disable to SIL3 and PL e
0.5 mA
Response time
Nominal: 8 ms
Maximum: 20 ms
The SAFE TORQUE OFF function may be used in a safety-related application in
preventing the drive from generating torque in the motor to a high level of
integrity. The system designer is responsible for ensuring that the complete
system is safe and designed correctly according to the relevant safety
standards. If the SAFE TORQUE OFF function is not required, these terminals
are used for enabling the drive.
41
Relay contacts
42
Default function Drive OK indicator
Contact voltage rating
240 Vac, Installation over-voltage
category II
Contact maximum current rating
2 A AC 240 V
4 A DC 30 V resistive load
0.5 A DC 30 V inductive load (L/R = 40 ms)
Contact minimum recommended
rating
12 V 100 mA
Contact type Normally open
Default contact condition Closed when power applied and drive OK
Update period 4 ms
51 0 V
52 +24 Vdc
Size 6
Nominal operating voltage 24.0 Vdc
Minimum continuous operating voltage 18.6 Vdc
Maximum continuous operating voltage 28.0 Vdc
Minimum startup voltage 18.4 Vdc
Maximum power supply requirement 40 W
Recommended fuse 4 A @ 50 Vdc
Size 7 to 10
Nominal operating voltage 24.0 Vdc
Minimum continuous operating voltage 19.2 Vdc
Maximum continuous operating voltage
30 Vdc (IEC),
26 Vdc (UL)
Minimum startup voltage 21.6 Vdc
Maximum power supply requirement 60 W
Recommended fuse 4 A @ 50 Vdc
To prevent the risk of a fire hazard in the event of a fault, a
fuse or other over-current protection must be installed in the
relay circuit.
