Digistart D3: User Guide 77
Issue: G
8H – Analog Output B
Description: Selects which information will be reported via the analog output. See Pr 8D Analog Output A for
details.
Current (% FLC) (default)
Current as a percentage of motor full load current.
Motor temperature as a percentage of the motor's thermal capacity.
Measured motor kilowatts, as a percentage of maximum kW.
Measured motor kilovolt amperes, as a percentage of maximum kVA.
Motor power factor, measured by the soft starter.
NOTE
Output B is only available if the input/output expansion card has been installed.
8I – Analog B Scale
Range: 0-20 mA
4-20 mA (default)
Description: Selects the range of the analog output.
8J – Analog B Maximum
Range: 0% - 600% Default: 100%
Description: Calibrates the upper limit of the analog output to match the signal measured on an external current
measuring device.
8K – Analog B Minimum
Range: 0% - 600% Default: 0%
Description: Calibrates the lower limit of the analog output to match the signal measured on an external current
measuring device.
8.8.10 Group 9 - Display
9A - Languages
Options: English Deutsch
Français Español
Italiano Chinese
Description: Selects which language the keypad will use to display messages and feedback.
