78 Digistart D3: User Guide
Issue: G
9B, 9C, 9D, 9E – User-Programmable Screen
Displays no data in the selected area, allowing long messages to be
shown without overlapping.
The starter's operating state (starting, running, stopping or tripped).
Only available for top left and bottom left positions on the screen.
The average current measured on three phases.
The motor's power factor, measured by the soft starter.
The average frequency measured on three phases.
The motor's running power in kilowatts.
The motor's running power in horsepower.
The motor's temperature, calculated by the thermal model.
The number of kilowatt hours the motor has run via the soft starter.
The number of hours the motor has run via the soft starter.
The level of analog input A (see Pr 8A~8C). This setting is only
available if the input/output expansion option is installed.
The motor’s apparent running power in kVA.
The motor’s running power as a percentage of rated kW. Power
factor is assumed to be 1.0 at 100% kW.
Whether the starter is controllign the motor using the primary motor
set (M1) or the secondary motor set (M2).
Description: Selects which information will be displayed on the programmable monitoring screen.
• 9B User Screen - Top Left Default: Motor Current
• 9C User Screen - Top Right Default: Motor pf
• 9D User Screen - Bottom Left Default: Hours Run
• 9E User Screen - Bottom Right Default: kWh
9F – Graph Data
The Digistart D3 has a real-time performance graph to report the behaviour of critical operating parameters.
Current (% FLC) (default)
Current as a percentage of motor full load current.
Motor temperature as a percentage of the motor's thermal capacity.
Measured motor kilowatts, as a percentage of maximum kW.
Measured motor kilovolt amperes, as a percentage of maximum kVA.
Motor power factor, measured by the soft starter.
√3 x average current x mains reference voltage x measured power
√3 x motor FLC x mains reference voltage. Power factor is assumed
to be 1
√3 x average current x mains reference voltage
√3 x motor FLC x mains reference voltage
Description: Selects which information the graph will display.
9G – Graph Timebase
Options: 10 seconds (default) 10 minutes
30 seconds 30 minutes
1 minute 1 hour
5 minutes
Description: Sets the graph time scale. The graph will progressively replace the old data with new data.
9H – Graph Maximum
Range: 0% – 600% Default: 400%
Description: Adjusts the upper limit of the performance graph.
9I – Graph Minimum
Range: 0% – 600% Default: 0%
Description: Adjusts the lower limit of the performance graph.
