Nidec Digistart D3 User Manual

Digistart D3: User Guide 81
Issue: G
8.8.13 Group 12 - Start/Stop Modes-2
For details of soft start and stop control methods, see Soft start methods on page 48 and Stop methods.
For details of parameter options, see Group 2 - Start/Stop Modes-1 on page 66.
12A – Start Mode-2
Options: Constant Current (default)
Adaptive Control
Description: Selects the soft start mode.
12B – Current Limit-2
Range: 100% - 600% FLC Default: 350%
Description: Sets the current limit for constant current and current ramp soft starting, as a percentage of motor
full load current.
12C – Initial Current-2
Range: 100% - 600% Default: 350%
Description: Sets the initial start current level for current ramp starting, as a percentage of motor full load
current. Set so that the motor begins to accelerate immediately after a start is initiated.
If current ramp starting is not required, set the initial current equal to the current limit.
12D – Start Ramp Time-2
Range: 1 - 180 (seconds) Default: 10 seconds
Description: Sets the total start time for an Adaptive Control start or the ramp time for current ramp starting
(from the initial current to the current limit).
12E – Adaptive Start Profile-2
Options: Early Acceleration
Constant Acceleration (default)
Late Acceleration
Description: Selects which profile the Digistart D3 will use for an Adaptive Control soft start.
12F – Kickstart Level-2
Range: 100% - 700% FLC Default: 500%
Description: Sets the level of the kickstart current.
12G – Kickstart Time-2
Range: 0 - 2000 (milliseconds) Default: 0000 milliseconds
Description: Sets the kickstart duration. A setting of 0 disables kickstart.
12H – Stop Mode-2
Options: Coast To Stop (default)
TVR Soft Stop
Adaptive Control
Brake
Description: Selects the stop mode.
12I – Stop Time-2
Range: 0:00 - 4:00 (minutes:seconds) Default: 3 seconds
Description: Sets the stop time.
12J - Stop Delay-2
Range: 0:00 - 1:00 (minutes:seconds) Default: 0 seconds
Description: Sets a delay after the starter receives a stop command, before it stops the motor.
