6.1.23 Motor cable size and maximum lengths
Table 6-20 Motor cable size and maximum lengths
6.1.24 Brake resistor values
Table 6-21 Minimum resistance values and peak power rating for the braking resistor at 40 °C (104 °F)
* Resistor tolerance: ±10 %.
Model
Number of input
phases
Output cable
All switching frequencies
mm
2
AWG
01200022 1 0.75 24
50 m
01200040 1 0.75 22
01200065 1 0.75 20
02200090 1 0.75 16
02200120 1 0.75 16
03200160 1 1.5 14
01200022 3 0.75 20
01200040 3 0.75 18
01200065 3 0.75 16
02200090 3 1.0 14
02200120 3 1.5 12
03200160 3 2.5 12
01400015 3 0.75 20
01400030 3 0.75 20
01400042 3 0.75 18
02400060 3 0.75 16
02400080 3 0.75 14
02400105 3 1.5 14
03400135 3 2.5 12
03400160 3 2.5 12
Model
Minimum resistance*
(Pr 10.061)
Peak power rating
Continuous power rating
(Maximum Pr 10.030 setting)
Maximum braking resistor
thermal time constant
(Pr 10.031)
Ω kW kW s
200 V
01200022 25 6 2 2
01200040 25 6 2 2
01200065 25 6 2 2
02200090 13 11.1 3.7 2
02200120 13 11.1 3.7 2
03200160 10 15 5 2
400 V
01400015 106 5.7 1.9 2
01400030 106 5.7 1.9 2
01400042 106 5.7 1.9 2
02400060 36 16.8 5.6 2
02400080 36 16.8 5.6 2
02400105 36 16.8 5.6 2
03400135 26 22.8 7.6 2
03400160 26 22.8 7.6 2
