26 Digitax HD M75X Series Installation and Technical Guide
Issue Number: 5
3.6.2 Drive width with option module support installed
Figure 3-12 Drive width with option module support installed
* Allow for up to +0.5 mm tolerance with each drive.
3.7 Ingress protection label
The ingress protection label (shown in Figure 3-13 below) must remain in place while the drive is mounted, and until all enclosure wiring has been
completed. The label should be removed before first power up.
Figure 3-13 Ingress protection label
1. Ingress protection label (Remove before use).
2. Tear off tab (Remove before use).
