Safety information Product information Mechanical installation Electrical installation Multi axis system design Technical data
Digitax HD M75X Series Installation and Technical Guide 113
Issue Number: 5
6.1.27 Optional External EMC filters
Table 6-36 Drive and EMC filter cross reference
6.1.28 EMC filter ratings
Table 6-37 Optional external EMC filter details
6.1.29 Overall EMC filter dimensions
Table 6-38 Optional external EMC filter dimensions
Model Number of phases Part number
200 V
01200022 1
4200-350301200040 1
01200065 1
02200090 1
4200-5033
02200120 1
03200160 1 4200-6034
01200022 3 4200-8744
01200040 3 4200-6002
01200065 3 4200-6001
02200090 3 4200-5833
02200120 3 4200-5833
03200160 3 4200-5833
400 V
01400015 to 01400042 3 4200-8744
02400060 to 02400105 3 4200-1644
03400135 to 03400160 3 4200-5833
Part number
Number of
phases
Maximum continuous
current
Maximum voltage
rating
Power
losses at
rated
current
IP
rating
Weight
Operational
leakage current
Worst
case
leakage
current
@40C
(104F)
@50C
(122F)
IEC UL
AAVVW kglbmA mA
4200-3503 1 30 27.3 250 250 6.1 20 0.7 1.5 5.4 10.8
4200-5033 1 55 50.1 250 250 9.9 20 1.2 2.6 11 22
4200-6034 1 65.7 60 250 250 5.5 20 1.8 4.0 3.4 6.8
4200-8744 3 7.7 7 480 480 3.8 20 0.5 1.1 33 178.2
4200-6002 3 11 10 480 480 10 20 1.2 2.64 16 90
4200-6001 3 17 15.5 250 250 13 20 1.2 2.64 8 50
4200-1644 3 17.5 16 480 480 6.1 20 0.8 1.76 33 178.2
4200-5833 3 32.9 30 480 480 11.8 20 1.2 2.64 33 178.2
4200-3233 3 46 42 480 480 15.7 20 1.4 3.1 33 178.2
4200-5534 3 60.2 55 480 480 25.9 20 2.0 4.4 33 178.2
4200-7534 3 82.2 75 480 480 32.2 20 2.7 6.0 33 178.2
4200-0035 3 109.5 100 480 480 34.5 20 4.3 9.5 33 178.2
Part number
Dimension
Weight
HW D
mm inch mm inch mm inch kg lb
4200-3503 149.5 5.89 105 4013 57.6 2.27 0.7 1.5
4200-5033 230 9.06 115 4.53 60 2.36 1.2 2.6
4200-6304 243 9.57 115 4.53 100 3.94 1.8 4.0
4200-6001 359 14.13 61 2.40 29 1.14 1.2 2.64
4200-6002 359 14.13 61 2.40 29 1.14 1.2 2.64
4200-1644 264 10.39 70 2.76 45 1.77 0.8 1.76
4200-8744 204 8.03 70 2.76 40 1.58 0.5 1.10
4200-3233 330 13.00 85 3.35 50 1.97 1.4 3.08
4200-5833 290 11.42 85 3.35 50 1.97 1.2 2.64
4200-5534 298 11.73 90 3.54 85 3.35 2.0 4.40
4200-7534 318 12.52 135 5.32 80 3.15 2.7 5.94
4200-0035 330 13.00 150 5.91 90 3.54 4.3 9.46
