NE200/300 Series Drive User Manual
Chapter 6 Parameter description 101
selected by the
②
SW1/
③
SW2 DIP switch on the control board.
3: PULSE setup
②
The reference frequency is given by the terminal pulse. Pulse
signal reference specification: voltage 9V ~12V and frequency range
0Hz ~200Hz.
③
The reference frequency is given by the terminal pulse. Pulse
signal reference specification: voltage 9V ~30V and frequency range
0kHz ~50kHz.
4: Communication
It means that the frequency source is given by the host computer via
the communication mode.
5: MS (Multi-step) Speed
When this mode is selected, group F6 “Input Terminals” and Group F9
“Multi-step speed and PLC” parameters shall be set to determine the
relative relationship between the reference signal and the reference
frequency.
6: Programmable Logic Controller (PLC)
When PLC mode is selected, Group F9 “Multi-step Speed and PLC”
parameters shall be set to determine the reference frequency.
7: PID
When PID is selected to be reference, Group F8 “PID Parameters”
shall be set. The running frequency of the drive is the value after PID
regulation.
8: keypad potentiometer
Note：
In Freq. ref. 1, the Multi-step option is prior to other frequency reference
