NE200/300 Series Drive User Manual
144 Chapter 6 Parameter description
Value Function Description
F6.00 terminal command modes setup.
45 Torque increase When the torque reference is given by
discrete signal, this function realizes the
torque increasing, decreasing, and increment
clearing. Refer to F3.24 and F3.25 for torque
increment and adjustment range.
46 Torque increase clear
47 Torque decrease
48
One key recover user
parameters (Valid in stop
state)
If the user has done the parameter backup
operation before, drive can be reset to those
parameters setting by this terminal under
stop state.
49~56 Reserved Reserved
57 Pulse input
High speed pulse input. This function is only
valid for X4 & X5. And X4 has priority when
there are 2 routes input.
58
③ Single phase
measuring speed input
Single phase measuring speed input. Only
valid for X4 and X5. Take X4 as priority
when there are 2 routes input.
59
③
Speed measuring
input A
Measuring speed input A. It is only valid for
X4
60
③
Speed measuring
input B
Measuring speed input B. It is only valid for
X5
Table 6-4 Multi-steps running selection guide
K4 K3 K2 K1 Freq. Setup Parameter
OFF OFF OFF OFF F0.06 F0.06
OFF OFF OFF ON Multi-step freq.1 F9.00
OFF OFF ON OFF Multi-step freq.2 F9.01
OFF OFF ON ON Multi-step freq.3 F9.02
OFF ON OFF OFF Multi-step freq.4 F9.03
OFF ON OFF ON Multi-step freq.5 F9.04
OFF ON ON OFF Multi-step freq.6 F9.05
OFF ON ON ON Multi-step freq.7 F9.06
