NE200/300 Series Drive User Manual
Chapter 6 Parameter description 145
ON OFF OFF OFF Multi-step freq.8 F9.27
ON OFF OFF ON Multi-step freq.9 F9.28
ON OFF ON OFF Multi-step freq.10 F9.29
ON OFF ON ON Multi-step freq.11 F9.30
ON ON OFF OFF Multi-step freq.12 F9.31
ON ON OFF ON Multi-step freq.13 F9.32
ON ON ON OFF Multi-step freq.14 F9.33
ON ON ON ON Multi-step freq.15 F9.34
Table 6-5 Acc/Dec time selection table
Terminal 2
Terminal 1 Acc/Dec time selection
OFF OFF Acc time 1/ Dec time 1
OFF ON Acc time 2/ Dec time 2
ON OFF Acc time 3/ Dec time3
ON ON Acc time 4/ Dec time4
F6.10 Analog Nonlinear Selection Range: 0~3【0】
0: None
F6.11～F6.15 are used to define AI1 inputs, F6.16～F6.20 are used to
define AI2 inputs, and F6.21～F6.25are used to defined pulse inputs.
They are independent and do not interfere to each other.
1: AI1
All the parameters from F6.11 to F6.25 are nonlinear setting points for
the AI1 channel, as shown in Fig.6-17. The AI1 filter time F6.15 is
taken. And AI2 setting points F6.16~6.20 are taken as 0.00~10.00V
input and its corresponding 0.00~100.00%.setup value. And pulse
input setting points are taken as 0.00~50.00 kHz and its
corresponding 0.00~100.00% setup value.
