First Steps
Charge the Battery
The camera is powered by an EN-EL9a rechargeable Li-ion battery (supplied).
To
maximize shooting time, charge the battery in the supplied MH-23 quick charger
before use.
About one hour and forty minutes are required to fully recharge the
battery when no charge remains.
1 Plug the charger in.
Insert the AC adapter plug into the battery
charger and plug the power cable into an
electrical outlet.
2 Remove the terminal cover.
Remove the terminal cover from the battery.
3 Insert the battery.
Insert the battery as shown in the illustration on
the charger.
The CHARGE lamp will blink while the
battery charges.
4 Remove the battery when charging is
complete.
Charging is complete when the CHARGE lamp
stops blinking.
Remove the battery and unplug
the charger.
EL-EL9a
7.2V 1080mAh
7.8Wh
Terminal
cover
Battery
charging
Charging
complete
EL-EL9a
7.2V 1080mAh
7.8Wh
