1097
Specifications
Viewfinder
Viewfinder Eye-level pentaprism single-lens reflex viewfinder
Frame
coverage
•
FX: Approx. 100% horizontal and 100% vertical
•
1.2×: Approx. 97% horizontal and 97% vertical
•
DX: Approx. 97% horizontal and 97% vertical
•
5:4: Approx. 97% horizontal and 100% vertical
•
1:1: Approx. 95% horizontal and 100% vertical
•
16:9: Approx. 100% horizontal and 96% vertical
Magnification Approx. 0.72× (50 mm f/1.4 lens at innity, −1.0 m
−1
)
Eyepoint
17 mm (−1.0 m
−1
; from center surface of viewfinder
eyepiece lens)
Diopter
adjustment
−3–+1 m
−1
Focusing
screen
Type B BriteView Clear Matte Mark X screen (with AF-
area brackets; framing grid can be displayed)
Reflex mirror Quick return
Depth-of-field
preview
Pressing Pv button stops lens aperture down to value
selected by user (A and M modes) or by camera (P and S
modes)
Lens aperture Instant return, electronically controlled
