Nikon D60 Repair Manual

VBA21001-R.3753.A
- R1
･
-
logo_Q0650_forGraphic
071004_Gdesign_ito
Items Judgment standard Remarks
External view
Step
(height difference)
Clearance
Between top cover and apron: 0.2 mm or less
Other parts: 0.3 mm or less; Inside elements must not be seen.
Moving parts: 0.5 mm or less
from Top cover to Apron; to rear cover: 0.2 mm or less
from Bottom cover to Apron; to rear cover: 0.2 mm or less
When SB is housed, from SB upper case to Top cover; to
Apron: 0.5 mm or less
Other parts: 0.3 mm or less; Inside elements must not be
seen.
Moving parts: 0.5 mm or less
Visual check
Digital micrometer
Size / Force
Shutter release button
Aperture lever
Main mirror
Sub-mirror
Finder ∞ Infinity
focus
Protrusion: 1.05 ± 0.2 mm
Halfway pressing force: 100 ± 50 g
Halfway pressing stroke: 0.5 ± 0.2 mm
Releasing force: 260 ± 70 g
Releasing stroke: 0.7 ± 0.25 mm
Full stroke: 0.6 mm or more
Difference btwn Half-releasing and Full pressing force:
51 g or more
Height: 3.4 + mm
45 ゜ angle: Up-down ± 10'
Right-left ± 30'
Distortion: 6' or less
Clearance for up-mirror in mirror box: None
47.75 ゜ angle: Up-down
Collimator measurement value: 0’
Distortion: 8’ or less
±100μm
Digital micrometer
Tension gauge
3.4 height gauge
Collimator
Main mirror tool
Visual check
Feeling in hand
Sub-mirror tool
Collimator
∞ focus lens
Inspection standards
+0.20
- 0.10
+20′
- 45′
INC

Nikon D60 Specifications

General

Megapixel	10.2 MP
Sensor type	CCD
Maximum image resolution	3872 x 2592 pixels
Interface	USB
Digital SLR	Yes
Video capability	No
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
Product color	Black
Battery type	EN-EL9
Battery capacity	1000 mAh
Flash modes	auto, Flash off
Scene modes	Children, Close-up (macro), Night portrait, Portrait, Sports, Landscape (scenery)

Weight and Dimensions

Depth	64 mm
Width	126 mm
Height	94 mm
Weight	495 g
