303
3 Position the MB-D18, keeping the MB-D18 mounting screw
(w) aligned with the camera tripod socket (q), and tighten
the attachment wheel by rotating it in the direction shown
by the LOCK arrow.
There is no need to remove the battery from the camera
before connecting the MB-D18. At default settings, the
battery inserted in the camera will be used only after the
battery in the MB-D18 is exhausted. The Battery order
option in the camera setup menu can be used to change the
order in which the batteries are used.
D Attaching the Battery Pack
Be sure to place the camera contact cover in the contact cover holder
and to keep the MB-D18 contact cap in a safe place to prevent loss. A
PB-6D bellows spacer and PK-13 auto extension ring are required
when using PB-6 bellows focusing attachment with the MB-D18.
