MACHINE DESCRIPTION
MACHINE STRUCTURE (as shown in Figure 1)
1. Steering wheel
2
. Seat cushion
3
. Recovery tank cover
4
. Utility caddy (*)
5
. USB charging port
6
. Front lights
7
. Front wheel & Drive motor
8
. Brush
9
. Brush assembly
10
. Brush deck
11
. Rear wheel
12
. Squeegee assembly
13
. Solution outlet cover
14
. Mop frame (*)
15
. Recovery tank
16. Warning light (*)
17
. Recovery tank drain hose
18
. Tank
19
. Squeegee adjustment knob
20
. Vacuum hose
21
. Squeegee knob
22
. Squeegee hasp
23
. Control panel
24
. Key switch
25
. Emergency switch
26
. Accelerate pedal
27
. Solution level indicator
28
. Batteries (*)
29
. Battery tray for wet battery (*)
(*): Optional
29
12
10
9
6
5
32
1
11
8
7
4
15
14
13
16
28
27
24
23
22
21
20
19
18
17
26
25
Figure 1
