NOTE
In the process of charging, if the yellow light (52) is on, it may be caused by: Battery and
charger doesn’t match, battery is not
connected well, or output is short-circuited.
The red light of charger flashing may be caused by the charger internal short circuit.
MACHINE DESCRIPTION
TECHNICAL PARAMETERS
Rated power (W) 2658
Airflow (l/sec.) 19.46
Vacuum (kPa) 15.5
Voltage (V) 24
Sound pressure level at 1.5 m (dB(A) ISO 3744) 69
Max. speed (km/h) 6
Length x width x height (mm）
1620x760x1250
Brush speed (RPM) 180
Solution/recovery tank (l) 110/110
Brush pressure (kg) 35/50
Scrubbing width (mm) 710
Min. turn-around aisle width (cm) 225
Max. climbing rate (%) 10
Productivity theoretical/actual (m²/h) 4260/2980
Insulation class III
Brush/pad diameter (mm) 355/355
IP protection class IP24
Net weight (kg) 230
Water flow (l/m) 1.2/3.5
Vacuum motor power (W) 500
Max. running time 4
Brush motor (W) 500
Battery compartment size (L x W x H) (mm) 590x390x350
Gross weight (gvw) (kg) 545
Brush quantity and type 2 Disc
Technical Specification Technical Specification Value
