General Information 16Service Manual – SC6500
™
**Transportation Weight: Standard machine without options, empty solution and recovery tanks, with
batteries installed and no operator.
Nilfisk Brand SC6500 Models
Model (with and without EcoFlex) 1100C 1300C
. 1100D 1300D
Model No 56414023
56414022
56414025
56414024
Voltage, Batteries V 36V 36V
Battery Capacity Ah 480 480
Protection Grade IPX3 IPX3
Sound Pressure Level
IEC 60335-2-72: 2002 Amend. 1:2005, ISO
11201
dB(A)/20µPa 70 70
Sound Pressure level - KpA
(IEC 60335-2-72, ISO 11201) Uncertainty
dB(A) 3.0 3.0
Gross Weight* - Cylindrical lbs / kg 3325 / 1508 3410 / 1547
Transportation Weight** - Cylindrical lbs / kg 2897 / 1314 2982 / 1353
Gross Weight* - Disc lbs / kg 3220 / 1460 3320 / 1506
Transportation Weight** - Disc lbs / kg 2792 / 1266 2892 / 1312
Maximum Wheel Floor Loading (center
front)
psi / kg/cm2 116 / 8.15 116 / 8.15
Maximum Wheel Floor Loading (right rear) psi / kg/cm2 81 / 5.69 81 / 5.69
Maximum Wheel Floor Loading (left rear) psi / kg/cm2 86 / 6.04 86 / 6.04
Vibrations at the Hand Controls (ISO 5349-
1)
m/s2 <1.12m/s2 <1.12m/s2
Vibrations at the Hand Controls (ISO 5349-
1) Uncertainty
m/s2 .11 m/s2 .11 m/s2
Vibrations at the Seat (EN 1032) m/s2 <0.35m/s2 <0.35m/s2
Vibrations at the Seat (EN 1032)
Uncertainty
m/s2 0.035m/s2 0.035m/s2
Gradeability - Transport 16% (9°) 16% (9°)
Gradeability - Cleaning 10.5% (6°) 10.5% (6°)
Machine Length inch / cm 73.5 / 187
Machine Height inch / cm 58.5 / 148.6
Machine Height (w/overhead guard) inch / cm 84 / 213
Machine Width at Rollers - Cylindrical inch / cm 47.5 / 121 55.5 / 141
Machine Width at Rollers - Disc inch / cm 42.5 / 108 52.5 / 133
Machine Width with Squeegee inch / cm 49 / 125 “F” 57 / 145 “H”
Minimum Aisle Turn Width inch / cm 84 / 214
Solution Tank Capacity Gallon / L 70 / 265
Recovery Tank Capacity Gallon / L 70 / 265
Transport Speed (Fwd. Maximum) mph / kph 6.0 / 9.5
Transport Speed (Rev. Maximum) mph / kph 3.0 / 5.0
