Electrical System 60Service Manual – SC6500
™
Note: The following table represents how many “bars” are displayed in the battery indicator icon
based on the actual battery voltage.
Battery Indicator Standard Alternate
5 vertical indicator bars 36.1+ 36.1+
4 vertical indicator bars 35.5-36.1 35.5-36.1
3 vertical indicator bars 34.4-35.5 34.4-35.5
2 vertical indicator bars 33.9-34.4 33.9-34.4
1 vertical indicator bars 32.2-33.9 33.3-33.9
0 vertical indicator bars 30.9-32.2 32.8-33.3
Low-voltage Cut-out <30.9 <32.8
