Service Manual: SC750, SC800, SC 750 ST, SC800 ST
Form Number 56043150 Page 133
Drive Wheels Diameter: 10 in (25.4 cm) Width: 3 in (7.62 cm)
Type/Material: Polyurethane Foam - molded
Drive Motor .4 HP (298 was)
Max. Transport Speed Fwd: 5.75 km/h (3.57 mph)
Rev: 4.36 km/h (2.71 mph)
Drive Motor
Amp Draw Measurements
• No load (one wheel jacked up), jumped directly to baery- Approximately 1.8 amps
• Traversing on level oor with empty tanks driven by Drive Motor Controller at highest speed – Approximately 4-5
amps (Note: Amp draw is higher when geng up to speed – approximately 10 – 12 amps.)
Potentiometers
Speed Limit Potenometer – 100K ohms
Paddle Posion Potenometer – 5K ohms
