Engine System - Petrol 103Service Manual – SW4000
Specications
Engine System - Petrol
Values
SW4000 Petrol
Make Honda
Model GX-200
Regulated power (ISO 1585) 6.7 kW
Working speed 2,750 ± 50 rpm
Oil type SAE 5 W 30 - SYNTHETIC API SJ
Average consumption 0.45 gph US (1.7 liters/hour)
Fuel tank capacity 2.0 gal US (7.8 liters)
Reserve 0.6 gal US (2.2 liters)
Length Width Height (engine only) 12.3 x 14.8 x 13.2 in (313 x 376 x 335 mm)
Displacement (bore x stroke) 12 in
3
[2.68 x 2.13 in] (196 cm
3
[68 x 54 mm])
Maximum output 4.8 kW (6.5 PS) at 3,600 min (rpm)
Max torque 117 lbf•in - 2,500 rpm (min) (13.2 N•m (1.35 kgf•m) at 2,500 min (rpm))
Engine oil quantity 0.16 gal US (0.60 liters)
Cooling system Forced air
Starting system Transistor magnet
PTO shaft rotation Counter-clockwise
Distance between the spark plug electrodes 0.028 - 0.031 in (0.70 - 0.80 mm)
Idle speed 1,400 min (rpm)
Valve clearance (cold)
INTAKE: 0.0059 ± 0.00079 in (0.15 ± 0.02 mm)
EXHAUST: 0.0079 ± 0.00079 in (0.20 ± 0.02 mm)
Fuel
Unleaded fuel
U.S.A.: Pump octane number not less than 86
Except in the U.S.A.: Research octane number not less than 91
Except in the U.S.A.: Pump octane number not less than 86
Spark plug
BPR6ES (NGK)
W20EPR-U (DENSO)
