Service Manual – SW4000
Technical Data
Model SW4000 B SW4000 P SW4000 LP
Cleaning width with one side broom 38.3 in (975 mm)
with two side brooms 49.2 in (1,250 mm)
Main broom size (length x diameter) 27.6 x 13.4 in (700 x 340 mm)
Side broom diameter 17.7 in (450 mm)
Theoretical working capacity main broom 52,743 ft
2
/h (4,900 m
2
/h)
with two side brooms 73,463 ft
2
/h (6,825 m
2
/h)
with two side brooms 94,184 ft
2
/h (8,750 m
2
/h)
Hopper capacity 19.8 US gal (75 liters)
maximum liftable weight 220 lb (100 kg)
maximum lifting height 62.6 in (1,590 mm)
Filter cleaning system Electrical lter shaker
area 75 ft
2
(7 m
2
)
ltering capacity 4 µm
Power source 24 Volt batteries -
Power - 4,1 kW (5,5 CV) @ 3.600 giri/min
Engine model (*) - Honda GX-200
Tank capacity - 2 US gal
(7,8 litres)
-
LPG Tank capacity - - 33 lb (15 Kg)
Main broom motor power 0.8 hp (600 W)
speed 550 rpm
Side broom motor power 0.12 hp (90 W)
speed 110 rpm
Vacuum motor power 0.35 hp (260 W)
Drive type Electric drive on front wheel
gearmotor power 1.35 hp (1,000 W)
forward speed 4.3 mi/h (7 km/h)
reverse speed 2.8 mi/h (4.5 km/h)
Maximum gradient when working 20 %
Hopper hydraulic control unit 0.33 hp (250 W)
Filter shaker motor 0.12 hp (90 W)
Total absorbed power 2.7 hp (2.0 kW)
Working autonomy 4,5 h 13 h 25 h
Dimensions
(length x width x height)
machine body 64.5 x 40.7 x 52.3 in (1,640 x 1,035 x 1,330 mm)
machine with side brooms 64.5 x 41.3 x 52.3 in (1,640 x 1,050 x 1,330 mm)
machine with ashing light 64.5 x 41.3 x 57.7 in (1,640 x 1,035 x 1,390 mm)
machine with FOPS protective roof (optional) 64.5 x 40.7 x 78.3 in (1,640 x 1,035 x 1,990 mm)
battery compartment 14.5 x 32 x 15.3
in (370x812x390
mm)
14.2 x 15 x 8.7 in
(360 x 380 x 220 mm)
LPG tank maximum size (length x diameter) - - 28.3 x 11.8 in
(720 x 300 mm)
