Electrical System 89Service Manual – SW4000
Specications
Electrical components
Values
SW4000 Battery SW4000 Petrol SW4000 LPG
Total absorbed power 2.7 hp (2.0 kW)
Batteries
Values
SW4000 Battery
Battery pack 1 12 x 2V x 360A 6 EPzS 360 (WET)
Battery pack 2 12 x 2V x 360A 6 EPzV 330 (GEL-AGM)
Size (length x width x height) 32.0 x 14.8 x 15.4 in (812 x 375 x 390 mm)
Battery pack 3 12 x 2V x 330A 12-55L-13 330 (WET)
Battery pack 4 4 x 6V x 255A FF 06 255 (WET)
Battery pack 5 4 x 6V x 180A (GEL-AGM) DF 06V 180A
Size (length x width x height) 16.6 x 24.8 x 5.9 in (420 x 630 x 150 mm)
Battery compartment maximum size (width x length x height) 32.0 x 14.8 x 14.6 in (812 x 375 x 370 mm)
Battery charger
Values
SW4000 Battery
Input 230V ± 15% 50/60Hz (Imax:15A)
Output 24V 30A
Efciency >90%
Min. Vbatt 2V
Casing protection IP30
Batteries
Values
SW4000 Petrol SW4000 LPG
Battery pack 2 x 12V 77Ah
Size (length x width x height) 15.0 x 14.2 x 8.9 in (380 x 360 x 225 mm)
Electrical components
Values
SW4000 Battery SW4000 Petrol SW4000 LPG
Dynamotor - 1,400 W - 24V (70A - 1,600 rpm)
