INSTRUCTIONS FOR USE ENGLISH
14 664 7 2000 - S W 5 5 00, F L O O R T E C R 9 8 5 19
03/2016
BEFORE MACHINE START-UP
Checklist
1. ave a full knowledge of the machine operating controls and their functions.
2. nsert the ke (51) and start the machine (see the procedure in the following paragraph).
3. n the first 2 seconds after turning on, the multifunction displa (71) shows the machine working hours (71-A), the tpe of
b a t t e r i e s se t ( 7 1- B ) a n d t h e cu r r e n t m a xi m u m m a ch i n e sp e e d se t t i n g ( 7 1- C ) .
4 . Check the fuel reserve icon (71-P) if it is lit, range will e limited. Refuel with diesel or replace the LPG tank (see previous
p a r a g r a p h ) .
5 . Check the horn with switch (65), the reverse gear uer with switch (64) and the working light switch (67, optional) for proper
o p e r a t i o n .
6. Check the parking rake (7 and 6). The rake must hold its (locked parked) setting firml without easil eing released (report
all defects immediatel to Nilfisk Service Center).
7 . Check the service rake pedal (6) for proper operation.
WARNING!
If the pedal is “spongy” or fades under pressure without an efcient braking force, do not drive the machine
(report all defects immediately to Nilsk Service Center).
8 . Make sure that there are no open doors/hoods and that the machine is in normal operating conditions.
Cleaning planning
1. A r r a n g e l o n g r u n s w i t h a m i n i m u m o f st o p p i n g o r st a r t i n g .
2. A l l o w a sm a l l a m o u n t o f b r o o m p a t h o ve r l a p t o e n su r e co m p l e t e co ve r a g e .
3. Avoid making sharp turns, umping or scraping the side of the machine.
Filling the DustGuard™ system water tank (optional)
1. Remove the plug (25) to reach the filler neck.
2. Fill the tank (24) with clean water. o not fill the tank completel, leave a few centimetres from the edge.
STARTING AND STOPPING THE MACHINE
Starting the machine
1. S i t o n t h e d r i ve r ’ s se a t ( 3) a n d a d j u st i t w i t h t h e l e ve r ( 4 ) t o a l l o w e a sy r e a ch o f a l l co n t r o l s.
N O T E
The driver’s seat (3) is equipped with a safety sensor, which allows the machine to be driven only when the operator is
on the driver’s seat.
2. Turn the ignition ke (51) clockwise to the position.
3. ait for the multifunction displa to show the work screen (71-).
4 . Turn the ignition ke (51) to the start position , then release it when the engine starts.
5 . A f t e r st a r t i n g , l e t t h e e n g i n e i d l e f o r a f e w se co n d s.
CAUTION!
When starting do not press the accelerator pedal (5).
6. isengage the parking rake.
7 . rive the machine to the working area, manoeuvring it turning the steering wheel with our hands (1) and pressing the
a cce l e r a t o r p e d a l ( 5 ) .
T h e sp e e d ca n b e a d j u st e d b y a p p l yi n g m o r e o r l e ss p r e ssu r e t o t h e a cce l e r a t o r p e d a l ( 5 ) .
T h e m a xi m u m r u n n i n g sp e e d ca n b e se t w i t h p u s h - b u t t o n s ( 5 8 ) a n d ( 5 9 ) .
8 . T h e f o r w a r d /r e ve r se d i r e ct i o n i s se l e ct e d w i t h t h e r e l e va n t p u sh - b u t t o n ( 64 ) o n t h e d a sh b o a r d . A ct i va t i o n o f r e ve r se g e a r i s
i n d i ca t e d b y t h e b u zze r a n d o n t h e d i sp l a y ( 7 1- H ) .
WARNING!
When steering, avoid abrupt direction changes, pay careful attention and drive the machine at slow speed,
especially when the hopper is full or when operating on inclines.
Drive the machine slowly on inclines. Use the brake pedal (6) to control machine speed while descending
inclines.
Do not turn the machine on an incline; drive straight up or down.
N O T E
The machine has an anti-skid safety system, which where necessary reduces speed when steering and when the
machine is driving on a camber, regardless of the pressure applied to the pedal.
This reduction in speed is therefore not a malfunction but a characteristic which increases the stability and safety of the
machine in all conditions.
