INSTRUCTIONS FOR USE ENGLISH
14 664 7 2000 - S W 5 5 00, F L O O R T E C R 9 8 5 39
03/2016
BATTERY CHARGING (only for version with optional hybrid KIT installed)
CAUTION!
Charge the batteries with the installed battery
charger when the last segment of the battery icon
(A, Fig. 29) starts ashing
, or at the end of
each job. Keeping the batteries charged make
their life last longer.
Recharging is essential when the multifunction
display shows screen (B).
WARNING!
When the batteries are discharged, charge them
as soon as possible, as that condition makes
their life shorter.
1. D r i ve t h e m a ch i n e o n a l e ve l g r o u n d a n d e n g a g e t h e
parking rake.
2. Turn the ignition ke (51) to 0.
3. C o n n e ct t h e b a t t e r y ch a r g e r p l u g ( D ) t o a m a i n s e l e ct r i ca l
socket.
WARNING!
Check that the voltage and frequency shown on
the battery charger plate (D) match the mains
supply values.
N O T E
When the battery charger is connected to the
electrical mains, all machine functions are
automatically cut off.
The multifunction display shows the screen (C) as in
the gure.
4 . W h e n t h e b a t t e r y ch a r g e r g r e e n b a t t e r y sym b o l ( E ) i s
ashing, the atteries are recharging.
5 . W h e n t h e b a t t e r y ch a r g e r g r e e n b a t t e r y sym b o l ( E ) i s l i t
st e a d i l y , t h e b a t t e r i e s a r e ch a r g e d .
6. F o r f u r t h e r i n f o r m a t i o n a b o u t t h e b a t t e r y ch a r g e r o p e r a t i o n ,
se e t h e B a t t e r y C h a r g e r M a n u a l .
7 . D i sco n n e ct t h e b a t t e r y ch a r g e r ca b l e f r o m t h e e l e ct r i ca l
m a i n s.
A
B
C
E
OK
CHARGE
P 1009 24
Figure 29
