INSTRUCTIONS FOR USE ENGLISH
14 664 7 2000 - S W 5 5 00, F L O O R T E C R 9 8 5 33
03/2016
N O T E
To prevent water from owing out when cleaning the
lter, turn on the dust guard system and empty the
system tank (23).
1. D r i ve t h e m a ch i n e o n a l e ve l g r o u n d .
2. Turn the ignition ke (51) to 0 and engage the parking
rake.
3. L i f t a n d r e m o ve t h e l e f t si d e p a n e l ( 32) t o r e a ch t h e w a t e r
filter asseml (A, Fig. 22) of the dust control sstem.
4 . U n scr e w a n d r e m o ve t h e t r a n sp a r e n t co ve r ( B ) w i t h t h e
gasket (C), then remove the filter strainer ().
5 . C l e a n a n d i n st a l l t h e m o n t h e su p p o r t ( E ) .
N O T E
Install the gasket (C) and the lter strainer (D) in
the housings of the cover and of the lter assembly
holder.
A
B
C
D
E
P 1009 16
Figure 22
DUSTGUARD™ SYSTEM WATER FILTER CLEANING (OPTIONAL)
HYDRAULIC SYSTEM OIL LEVEL CHECK
WARNING!
Procedure to be performed with the hopper (11)
fully retracted.
1. Turn the ignition ke (51) to 0 and engage the parking
rake.
2. O p e n t h e e n g i n e co m p a r t m e n t h o o d ( 19 ) a n d f a st e n i t w i t h
t h e su p p o r t r o d ( 4 7 ) .
3. Check that the oil level in the hdraulic sstem tank (46) is
etween the minimum (MN) and maximum (MA) marks
shown in figure 23.
4 . I f n e ce ssa r y , a d d o i l t h r o u g h t h e p l u g ( A ) , u si n g t h e o i l
specified in Technical ata paragraph.
5 . R e m o ve t h e su p p o r t r o d ( 4 7 ) a n d cl o se t h e h o o d ( 19 ) .
A
MAX
MIN
P 1009 17
Figure 23
