ENGLISH INSTRUCTIONS FOR USE
30 S W 5 5 00, F L O O R T E C R 9 8 5 - 14 664 7 2000
03/2016
WARNING!
It is advisable to wear protective gloves when
replacing the side broom because there can be
sharp debris between the bristles.
1. D r i ve t h e m a ch i n e o n a l e ve l g r o u n d a n d e n g a g e t h e
parking rake.
2. Turn the ignition ke (51) to 0.
3. R e m o ve t h e p i n cl i p ( A , F i g . 15 ) , t h e n r e m o ve t h e p i n .
4 . Remove the room (B) and recover the protection ange
( C ) .
5 . I n st a l l o n t h e h u b ( D ) t h e n e w si d e b r o o m w i t h t h e
protection ange.
6. I n se r t t h e f a st e n i n g p i n a n d e n g a g e i t s sa f e t y cl i p .
7 . Check and adust the side room height as shown in the
p r e vi o u s p a r a g r a p h .
A
B
C
D
P 1009 09
Figure 15
SIDE BROOM REPLACEMENT
