ENGLISH INSTRUCTIONS FOR USE
22 S W 5 5 00, F L O O R T E C R 9 8 5 - 14 664 7 2000
03/2016
HOPPER DUMPING
WARNING!
The hopper (12) must be emptied on level grounds only.
Do not lift the hopper when the machine is on a slope.
WARNING!
When lifting and dumping the hopper (12), make sure that there are no people around the machine, especially
near the hopper.
N O T E
When the hopper (12) is lifted, the vacuum system turns off automatically and the machine maximum speed is reduced
for safety reasons.
T o e m p t y t h e h o p p e r , m o v e t h e m a ch i n e cl o se t o t h e d u st b i n a n d p r o ce e d a s f o l l o w s.
1. L i f t t h e si d e a n d m a i n b r o o m s.
2. P r e ss t h e e n a b l e p u sh - b u t t o n ( 66) w h i l e p r e ssi n g t h e h o p p e r l i f t i n g p u sh - b u t t o n ( 61) t o l i f t t h e h o p p e r ( A , F i g . 2) u p t o t h e
d e si r e d p o si t i o n .
3. rive the machine to the disposal area and engage the parking rake.
4 . R o t a t e t h e h o p p e r ( B ) w i t h t h e e n a b l e p u sh - b u t t o n ( 66) a n d p u sh - b u t t o n ( 62) t o d u m p t h e a ccu m u l a t e d w a st e ( C ) .
CAUTION!
The hopper (A) can be dumped only when lifted at a minimum height of 35 cm approximately.
The maximum dumping height is approx. 150 cm.
5 . Rotate the hopper ack with the enale push-utton (66) and push-utton (63).
6. L o w e r t h e h o p p e r b y p r e ssi n g b o t h t h e e n a b l e p u sh - b u t t o n ( 66) a n d p u sh - b u t t o n ( 61) a t t h e sa m e t i m e .
CAUTION!
Check that the hopper opening icon (71-K) on the display disappears and the buzzer stops to be sure that the
hopper (12) has fully returned to its working position.
7 . T h e m a ch i n e i s r e a d y t o st a r t sw e e p i n g a g a i n .
max
240 Kg
(530 lb)
A
C
B
max
1500 mm (59 in)
P 1008 9 5
Figure 2
