ENGINE OIL LEVEL CHECK AND OIL REPLACEMENT (DIESEL version)
Engine oil level check
CAUTION!
Running the engine with a low oil level can
damage the engine itself.
1. D r i ve t h e m a ch i n e o n a l e ve l g r o u n d a n d e n g a g e t h e
parking rake.
2. Turn the ignition ke (51) to 0.
3. O p e n t h e e n g i n e co m p a r t m e n t h o o d ( 19 ) a n d f a st e n i t w i t h
t h e su p p o r t r o d ( 4 7 ) .
4 . L i f t a n d r e m o ve t h e l e f t si d e p a n e l ( 32) .
5 . R e m o ve t h e ca p ( A , F i g . 24 ) .
6. Check the oil level. f it is elow the upper limit (B), top up
w i t h t h e r e co m m e n d e d o i l u n t i l yo u r e a ch t h e u p p e r l i m i t .
7 . Reinstall the filler cap (A) safel.
Engine oil change
CAUTION!
The discharged engine oil must be disposed of
properly according to the Law in force.
N O T E
It is advisable to change the oil when the engine is
still hot, to make the oil downow easier.
8 . P e r f o r m st e p s 1 t o 4 o f t h e p r e vi o u s p r o ce d u r e .
9 . R e m o ve t h e ca p ( A ) .
10. nhook the drain hose (C) and ring it towards the outside
o f t h e m a ch i n e .
11. R e m o ve t h e o i l d r a i n p l u g ( D ) f r o m t h e h o se a n d d r a i n t h e
oil into a suitale container, then refit the oil drain plug and
r e t u r n t h e h o se t o i t s i n i t i a l l o ca t i o n .
12. Pour the new oil through the filler () until it reaches the
u p p e r l i m i t ( B ) .
N O T E
As for engine oil type and quantity, see the Technical
Data chapter and the Engine Manual.
13. Reinstall the filler cap (A) safel.
A
B
C
E
D
DIESEL VERSION
LPG VERSION
P 1009 25
Figure 24
