ENGLISH INSTRUCTIONS FOR USE
32 S W 5 5 00, F L O O R T E C R 9 8 5 - 14 664 7 2000
03/2016
Preliminary Operations
1. E m p t y t h e h o p p e r ( a s sh o w n i n U se ch a p t e r ) , b e ca u se t h e
weight of the waste inside the hopper can affect the skirt
height check.
2. D r i ve t h e m a ch i n e o n a l e ve l g r o u n d t h a t i s su i t a b l e f o r
checking the skirt height.
3. Turn the ignition ke (51) to 0 and engage the parking
rake.
Side Skirt Check
4 . R e m o ve t h e l e f t a n d r i g h t d o o r s ( 14 a n d 13) b y t u r n i n g t h e
f a st e n e r s.
N O T E
The right door fasteners (13) must be turned with a
tool.
5 . Check the condition of the side skirts (A, Fig. 18) and (B).
Replace the skirts when the have cuts (C, Fig. 19) larger
than 20 mm or cracks/tears () larger than 10 mm (for skirt
r e p l a ce m e n t , r e f e r t o t h e S e r vi ce M a n u a l ) .
6. Check that the distance from the oor of the side skirts (A,
F i g . 18 ) a n d ( B ) i s w i t h i n 0 - 3 m m ( E , F i g . 20) .
I f n e ce ssa r y , l o o se n t h e n u t s ( F , F i g . 18 ) a n d a d j u st t h e
skirt position. Finall, tighten the nuts (F).
Front and Rear Skirt Check
7 . R e m o ve t h e m a i n b r o o m a s sh o w n i n t h e r e l e va n t
p a r a g r a p h .
8 . Check the condition of the front (G, Fig. 21) and rear skirts
( H ) a n d ( I ) .
Replace the skirts when the have cuts (C, Fig. 19) larger
than 20 mm or cracks/tears () larger than 10 mm.
9 . Check that the front (G, Fig. 21) and rear skirt () slightl
r u b g r o u n d w i t h o u t b e i n g d e t a ch e d f r o m i t ( J, F i g . 20) .
10. For the skirt replacement, see the Service Manual.
Reassembly
11. A sse m b l e t h e co m p o n e n t s i n t h e r e ve r se o r d e r o f
d i sa sse m b l y .
A F
P 1009 12
Figure 18
> 20 mm
(> 0,8 in)
> 10 mm
(> 0,4 in)
P 1009 13
Figure 19
0÷3 mm
(0÷0,12 in)
E J
P 1009 14
Figure 20
P 1009 15
Figure 21
SKIRT HEIGHT AND OPERATION CHECK
