ENGLISH INSTRUCTIONS FOR USE
40 S W 5 5 00, F L O O R T E C R 9 8 5 - 14 664 7 2000
03/2016
FUSE CHECK/REPLACEMENT
N O T E
All of the machine’s electronic circuits are protected by electronic devices which reset automatically. The safety fuses
blow only in the event of serious faults.
For this reason, fuses should only be replaced by qualied personnel.
Refer to the service manual available from Nilsk retailers.
SAFETY FUNCTIONS
T h e m a ch i n e i s e q u i p p e d w i t h t h e f o l l o w i n g sa f e t y f u n ct i o n s.
EMERGENCY PUSH-BUTTON
I t i s t o t h e l e f t si d e o f t h e o p e r a t o r ( 69 ) . I t h a s t o b e p r e sse d i n ca se o f e m e r g e n cy , t o st o p a l l t h e m a ch i n e f u n ct i o n s.
DRIVER’S SEAT MICROSWITCH
T h i s i s l o ca t e d i n si d e t h e d r i ve r ’ s se a t ( 3) a n d i t d o e s n o t a l l o w t h e m a ch i n e t o o p e r a t e i f t h e o p e r a t o r i s n o t se a t e d o n t h e d r i ve r ’ s
s e a t .
ANTI-SKID SAFETY SYSTEM
Reduces speed to a safe value, where necessar, when steering and when driving on a camer, in order to prevent skidding and
i n cr e a se t h e m a ch i n e ’ s st a b i l i t y i n a l l o p e r a t i n g co n d i t i o n s .
MACHINE ANGLE SENSOR
I f t h e h o p p e r i s t o b e r a i se d w i t h t h e m a ch i n e n o t o n l e ve l g r o u n d , t h e syst e m r e d u ce s t h e sp e e d o f m o ve m e n t o f t h e h o p p e r a n d
w a r n s t h e o p e r a t o r t h a t t h e m a ch i n e st a b i l i t y co n d i t i o n s m a y b e cr i t i ca l d e p e n d i n g o n t h e w e i g h t o f r e f u se co n t a i n e d , vi a a d i f f e r e n t
uer sound and the icon on the displa (71) as shown in figure 30.
HOPPER POSITION SENSOR
W h e n t h e h o p p e r i s l i f t e d , t h e se n so r r e d u ce s t h e m a ch i n e sp e e d , t u r n s o f f t h e va cu u m f a n a n d st o p s t h e b r o o m r o t a t i o n .
HOPPER SAFETY VALVE
W h e n t h e h o p p e r i s l i f t e d , t h e sa f e t y va l ve o n t h e h yd r a u l i c l i f t i n g cyl i n d e r p r e ve n t s t h e h o p p e r t o a cci d e n t a l l y l o w e r .
8.
P 1009 18
Figure 30
