Steering System 125Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Steering System
Functional Description
The steering system connects the steering wheel to the driving wheel assembly.
The reduction gear pinion transmits the movement to the steering crown connected to the driving wheel as-
sembly. The driving wheel assembly is also equipped with the gear for “magic deck” system movement.
To reach the steering system, the machine front fairing must be removed.
Component Location
Steering column
Front fairing
2
1
Front fairing
Steering column
P100756
