Nilfisk-ALTO SCRUBTEC R 466 Service Manual

Wheel System, Driving 142Service Manual – SCRUBTEC R466 ... FOCUS II Micro Rider
Specications
Description
SCRUBTEC
R 466
-
FOCUS II Micro
Rider
26D
SCRUBTEC
R 471
SCRUBTEC
R 471C
SCRUBTEC
BOOST
®
R4
-
FOCUS II Micro
Rider
28 BOOST
Rear wheel diameter
9.8 in (250 mm)
Rear wheel specic pressure on the oor (*) 130 psi (0.9 N/mm
2
)
Front steering, driving and braking wheel diameter 8.8 in (225 mm)
Front wheel specic pressure on the oor (*) 72 psi (0.5 N/mm
2
)
Driving wheel technical data
Max torque
100 Nm
Continuous torque
30 Nm
Load on the wheel
150 daN
Ratio
1/28.25
Drive system motor technical data
Power
0.4 hp (300 W)
Voltage
24 V
Speed
4200 rpm
Electrical input
15 A
Protection class
IP44
Electromagnetic brake technical data
Strength
4.0 Nm
Voltage
24 V
Maximum speed 3.7 mi/h (6 km/h)
Maximum gradient when working 2% (1.14°)
(*) Machines have been tested under the following conditions:
◦ With operator on board (165.3 lb - 75 kg)
◦ Maximum battery size
◦ Maximum brush and squeegee size
◦ Full clean water tank
◦ Optional components installed
◦ Weight on wheels checked
◦ Print on the oor checked on cement for each single wheel
◦ Result expressed as maximum value for front and rear wheels

Nilfisk-ALTO SCRUBTEC R 466 Specifications

General

Model	SCRUBTEC R 466
Voltage	24 V
Battery Voltage	24 V
Weight	200 kg
Machine weight	200 kg
