Nixeus NX-EDG34S User Manual

9
Installing the 75mm x 75mm Adapters for VESA Stands or Wall Mounting
1. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Remove the
extra parts and the foam covering the back of the monitor. If the monitor is already attached to the stand, remove the
stand.
2) If the stand was not installed, press the button to remove the stand plate.
3) Remove the original screws x 4 (1) from the opening in the back of the monitor and put them aside. Then use the
screws provided to attach the adapters inside the opening.
- Do not discard the original screws or the stand plate.
- Use only the screws provided. Refer to the image (2) for correct screw placement.
4) Follow the directions received with your mount, VESA stand, or 3
rd
party accessory and install the monitor on the wall
or fixture as desired.

Nixeus NX-EDG34S Specifications

General

Brand	Nixeus
Model	NX-EDG34S
Category	Monitor
Language	English
