2.5.2 Pilot Page selection
2 different pilot pages are available : analogue format or digital format (see § 2.3 for
customizing)
2.5.2.1 Gyropilot page
2.5.2.2 Digital Page
Press « OK »
to access the pilot mode and settings. Press « page » to
cancel the last action.
Gain value adjustable
with the up and down
arrows on the pad
Sensor identification
and value related to
the pilot mode.
Rudder angle
indicator
Access to the
pilot mode with
Course to steer
Sensor and value for
the related and
selected pilot mode.
Rudder angle
Pilot’s course to
steer
Pilot Mode.
Accessible with
the OK button.
User’s selected
data, set up
according to the
user’s preference
Gain value. Can be
adjusted with high and
low arrows of the key
pad
