3 INSTALLATION
This section describes the installation and configuration of the Multigraphic as well
as setting the parameters for an installation with a Gyropilot 2 processor. Refer to
the Gyropilot 2 manual for the full pilot installation (drive unit, processor, rudder
feed-back…).
3.1 Packing list. The Multigraphic comes with:
- A Multigraphic with six metres cable, featuring TOPLINE bus and an NMEA
port.
- A white sun cover
- A fixing bolt
3.2 Suggested spare parts list
- TOPLINE bus standard junction box: 90-60-121
- TOPLINE connection box with a NMEA port : 90-60-417
- White sun cover: 72-60-068
- Carbone sun cover : 72-60-071
3.3 Before installing check
The best location for the unit must be:
- Easy for the helmsman to read and operate,
- Safe location with low risk of shocks,
- More than 40 cm from a compass,
- Not horizontal.
Warning:
- Please take time to read this manual carefully before you start installation
- Any connection to the TOPLINE bus must be performed through the specific
interface box 90-60-417 (featuring an NMEA port) which comes with the
Multigraphic.
- Use only with the TOPLINE bus cable # 20-61-001.
- All Topline bus connections must be performed while the system is powered
off.
