48 50_Afficheur_Multigraphic_um_UK_27
2.8.1 Calibration wizard
Calibration wizards are available to help you calibrate the apparent wind angle, the
boat speed and a fluxgate compass (not available for the REGATTA compass).
2.8.1.1 Apparent Wind Angle calibration wizard
Sail 4 legs upwind to measure the average wind angle on each tack. A
wind vane offset will be calculated and applied to correct the Apparent
Wind Angle.
Apparent Wind Angle values must be similar from one tack to another
(+-1°) when the calibration is correct. If this is not the case, the wind
may have shifted, or the crew cannot sail with the same angle on each
tack upwind!
Calibration of the Apparent Wind Angle
Sail once again on starboard tack and port tack to fill the table for fine calibration.
Once this is done, you will be invited to save the new offset value.
