4 MULTIGRAPHIC SPECIFICATIONS
Dimensions With sun cover: 196 x 122 x 28mm (length x height x
depth)
Without sun cover: 192 x 118 x 23mm ((length x
height x depth)
Weight 800 g (with 6 m cable and sun cover)
Power supply 8V – 32V DC
Consumption at 12 Volts Day backlight:
Level 1 = 100mA
Level 20 = 180 mA
night backlight:
Level 1 = 100mA
Level 20 = 120mA
Standby: 91mA
NMEA input NMEA 183, baud rate configurable automatically from
4800 or 38400 bauds. AIS direct data acquisition.
Environment Protection IP 68 (waterproof at permanent immersion
and to high pressure water flow)
Operation temperature -20°C - +50°C
Storage temperature -20°C - +60°C
Power supply cable Ø 5.5 mm, 4 wires + braid, length 6m.
Display 5.7’’ colour graphic screen, translective, embedded
LED backlight.
