Note: when the pilot is disengaged «
---
» is displayed instead of the course to steer.
Operation with Apparent Wind mode
The compass mode requires a compass sensor, a boat speed sensor and a wind
sensor.
The apparent wind mode uses data from the mast head unit made available on the
Topline bus to steer the boat on a set Apparent Wind Angle. This mode is mainly
used while sailing upwind.
The following graphic shows the pilot page as it will be displayed on the
Multigraphic when the Gyropilot is engaged in Apparent Wind mode.
The Auto button engages the pilot and the Stop button disengages the pilot.
Make sure the pilot is disengaged before turning the power supply off.
Compass
Rudder angle
Gain Mode
Pilot type
Course to steer
To Next Page
