Nokia 5510 Owner's Guide

Getting started
12 Copyright © 2004 Nokia. All rights reserved
1. Indicates in which cellular
network the phone is being
used.
2. Shows the signal strength of
the cellular network at your
current location.
3. Shows the battery charge level.
4. Shows the current function of
the Nokia Navi™ key ( ).
■ Inserting a SIM card
• Keep all miniature SIM cards
out of the reach of small
children.
• The SIM card and its contacts
can easily be damaged by
scratches or bending, so be
careful when handling,
inserting or removing the card.
• Before installing the SIM card,
make sure that the phone is
switched off and then remove
the battery.
1. Press the locking catch, slide
the cover, and lift the cover off.
2. Press the two catches in
opposite directions and remove
the battery.
3. Slide the SIM card carefully
into the SIM card slot.
Make sure that the golden
connectors on the card are
facing downwards and that the
bevelled corner is on the left.
4. Align the golden connectors on
the battery with the
corresponding connectors on
the phone, and push the
Maverik_apac.fm Page 12 Thursday, October 7, 2004 2:03 PM

Nokia 5510 Specifications

General

Display	Monochrome graphic
Weight	155 g
Keyboard	QWERTY
Network Technology	GSM
2G bands	GSM 900 / 1800
GPRS	No
EDGE	No
Announced	2001
Status	Discontinued
SIM	Mini-SIM
Phonebook	Yes
Call records	10 dialed, 10 received, 10 missed calls
Loudspeaker	Yes
Alert types	Vibration; Downloadable monophonic ringtones
3.5mm jack	No
Games	Yes
Messaging	SMS
Clock	Yes
Alarm	Yes
Infrared port	Yes
Music player	Yes
Radio	Stereo FM radio
Java	No
Dimensions	134 x 58 x 28 mm
Stand-by	55 h - 260 h
Talk time	Up to 4 h 30 min
Colors	Blue
Battery	Removable Li-Ion 950 mAh battery (BLC-2)
