56 ã2000 Nokia Mobile Phones. All Rights Reserved.
S14 (n=1) and numerical (short format) responses
(n=0).
Bit-mapped options: bits 1, 2 and 3.
bit 1: 0=ATE0, 1=ATE1
bit 2: 0=ATQ0, 1=ATQ1
bit 3: 0=ATV0, 1=ATV1.
E.g. if bit 3 is 1, then the ATV1 command has been
executed.
The default values are shown in bold. The bits are
numbered from 0 to 7.
10
S21 For changing the S21 settings use the following AT
commands:
AT
&Cn to define the DCD signal usage. The DCD
signal is always on (n=0 or not present) or else used
in the normal way
(n=1),
AT
&Dn to define the DTR signal usage.
AT
&Sn to define the DSR signal usage. The DSR
signal is always on (n=0 or not present) or else used
in the normal way
(n=1).
Bit-mapped options: bits 3, 4, 5 and 6.
The default values are shown in bold.
bits 4
&3: 00=AT&D0, 01=AT&D1, 10=AT&D2,
11=AT
&D3
bit 5: 0=AT
&C0, 1=AT&C1
bit 6: 0=AT
&S0, 1=AT&S1
E.g. if bit 4 is 0 and bit 3 is 1, the command AT
&D1
has been executed.
112
S-Reg Unless otherwise specified the value range
Default
of the settings is from 0 to 255
