Figure 65 Bluetooth interface block diagram
Technical specifications
General specifications
Unit Dimension (mm) Weight (g) Volume (cc)
Transceiver with BL-4B
700 mAh Li-Ion battery
pack
88x43x23 104 g 76 cc
Battery endurance
Battery Talk time Standby time
BL-4B 700 mAh Li-ion 2.9 hours (RM-70) Up to 8 days
Note: Variation in operation times will occur depending on SIM card, network settings and usage.
Talk time is increased by up to 30% if half rate is active, and reduced by 5% if enhanced full rate is
active.
Environmental conditions
Temperature
Temperature range
Min
o
C Max
o
C
Operational (all specs met) -5 +55
Functional (reduced
performance)
-30 +70
Storage -30 +85
The HW module complies with the SPR4 Operating Conditions.
Humidity
Relative humidity range is 5...95%.
RM-70
System module Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 8 –21
Copyright © 2005 Nokia. All rights reserved.
