Mechanical parts list
Table 6 Mechanical parts list
ITEM QTY PART NAME
* = Not available as spare part
I001 1 A-COVER ASSY
A1 1 UI-SHIELD ASSY
I002* 1 UI SHIELD
I003* 1 EARPIECE
I004 1 LCD DISPLAY
A2 1 B-COVER ASSY
A3 1 B-COVER SERVICE ASSY (I005 & I006)
I005* 1 B-COVER
I006* 1 DEKO-PLATE
I101 1 SWIVEL
I102* 1 SCREWING PLATE
I103 2 SCREWS M2 x 3.7
I104 1 COAX CABLE
A4 1 LCD PWB ASSY (I301 - I303)
I301* 1 LCD PWB
I302* 1 LCD CONNECTOR
I303* 1 BOARD TO BOARD CONNECTOR
A5 1 C-COVER ASSY
I201* 1 C-COVER
I202 2 IHF SPEAKER
I203 1 MICROPHONE
I204* 1 VOLUME KEY
I205* 1 POWER KEY
I206* 1 CAMERA KEY
A6 1 PWB KEYMAT ASSY
I207* 1 PWB KEYMAT
I208 1 DOMESHEET (APAC & CHINA only)
I304* 4 LED
I210 1 KEYMAT
RM-70
Parts and layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –7
Copyright © 2005 Nokia. All rights reserved.
